Add the assembled top, front and bottom of the case next to the PCB photos, and
record what the nameplate says (manufacturer, the model description translated
from the Chinese label, 12 V DC 2 A and the serial number format) so a device
can be identified by its label. The top of the case carries no model name.

Also point out where the three console through-holes sit in the top side photo
and note the PWR and SFP1/SFP2 LEDs on the front panel; the case legend for the
copper LEDs reads 1000M/2500M.
